Acrel Open-loop Hall Effect Transducer (Split-core) AHKC-EKC

● Rated Input: 0~±500A DC or 0~500A AC

● Rated Input: 0~±1500A DC or 0~1500A AC
● Rated Output: 0~±5/±4Vdc
● Aperture: φ55mm
● Power Supply: ±12~±15Vdc
● Accuracy: Class 1.0
● Response Time: ≤5us
● Installation: Clamp on (Split-core) measuring cable and screw fixed on panel
● Standard&Certificate: CE; IEC; LVD
